NoHub-Standard Standard No-Hub Coupling

The original no hub coupling that is made in USA. A high quality low cost alternative where structural reinforcement does not require the use of a heavy duty coupling. In full compliance with ASTM 564, CISPI 310 and ASTM C1277, and also carries IAPMO, Canadian Std Association and NSF certification.



Standard No-Hub Coupling
Purchase Standard No-Hub Coupling
  • Standard No-Hub Coupling

  • The original no hub coupling that is made in USA. A high quality low cost alternative where structural reinforcement does not require the use of a heavy duty coupling. In full compliance with ASTM 564, CISPI 310 and ASTM C1277, and also carries IAPMO, Canadian Std Association and NSF certification.



    Material Specifications

    Shield Material:  300 SS
    Band Material: 300 SS
    Housing Material: 300 SS
    Screw Material: 300 SS
    Eyelet Material: 300 SS
    Gasket Material: ASTM C564 Compliant
    Installation Torque: 60 in-lbs
    Ultimate Torque: 75 in-lbs

Size Part No. Installation Torque Inch-Pounds No. of Clamps Per Coupling
1-1/2" 6217M8G 60 2
2" 6218M8G 60 2
3" 6219M8G 60 2
4" 6220M8G 60 2
5" 6221M8G 60 4
6" 6222M8G 60 4
8" 6223M8G 60 4
10" 6230M8G 60 4
2" x 1-1/2" 6233M8G 60 2
3" x 2" 62R198G 60 2
4" x 3"
62R208G 60 2
