P. 3
PREFORMED HOSE CLAMPS
Center Punch
Strapbinder’s double wrapped center punch preformed hose clamps are available in
various materials and diameters to satisfy a wide variety of applications. Available
in multiple diameters and 3/8" or 5/8" band widths, Strapbinder clamps can be
ordered in T201 stainless steel or high strength galvanized steel with heavy duty
stainless steel locks.
Tools for Product:
• Strapbinder HBC-300 tensioning tool (pg 9)
• Strapbinder F38 ratchet style application tool (pg 9)
• Strapbinder Grip Clamp tool #800800 (pg 8) for maximum installation efficiency
STAINLESS STEEL
Clamp I.D. Band Width Band Thickness Carton Weight
Item No. Qty/Box
inch mm inch mm inch mm lbs kg
HBCP3S 13/16 20.5 3/8 9.5 .025 .64 100 3.6 1.6
HBCP311S 1-3/8 34.8 3/8 9.5 .025 .64 100 4.6 2.1
HBCP4S 1 25.4 5/8 15.9 .025 .64 100 8.3 3.8
HBCP5S 1-1/4 31.7 5/8 15.9 .025 .64 100 8.7 3.9
HBCP6S 1-1/2 38.1 5/8 15.9 .025 .64 100 9.7 4.4
HBCP7S 1-3/4 44.4 5/8 15.9 .025 .64 100 10.6 4.8
HBCP8S 2 50.8 5/8 15.9 .025 .64 100 11.5 5.2
HBCP9S 2-1/4 57.1 5/8 15.9 .025 .64 100 12.6 5.7
HBCP10S 2-1/2 63.5 5/8 15.9 .025 .64 50 6.8 3.1
HBCP11S 2-3/4 69.8 5/8 15.9 .025 .64 50 7.3 3.3
HBCP12S 3 76.2 5/8 15.9 .025 .64 50 7.7 3.5
HBCP14S 3-1/2 88.9 5/8 15.9 .025 .64 50 8.7 3.9
HBCP16S 4 101.6 5/8 15.9 .025 .64 25 4.9 2.2
HBCP18S 4-1/2 114.3 5/8 15.9 .025 .64 25 5.5 2.5
HBCP20S 5 127.0 5/8 15.9 .025 .64 25 5.9 2.7
HBCP24S 6 152.4 5/8 15.9 .025 .64 25 6.8 3.1
HBCP28S 7 177.8 5/8 15.9 .025 .64 25 7.4 3.4
HBCP32S 8 203.2 5/8 15.9 .025 .64 25 8.2 3.7
GALVANIZED CARBON STEEL
Clamp I.D. Band Width Band Thickness Carton Weight
Item No. Qty/Box
inch mm inch mm inch mm lbs kg
HBCP3 13/16 20.5 3/8 9.5 .027 .69 100 3.6 1.6
HBCP311 1-3/8 34.8 3/8 9.5 .027 .69 100 4.6 2.1
HBCP4 1 25.4 5/8 15.9 .027 .69 100 8.3 3.8
HBCP5 1-1/4 31.7 5/8 15.9 .027 .69 100 8.7 3.9
HBCP6 1-1/2 38.1 5/8 15.9 .027 .69 100 9.7 4.4
HBCP7 1-3/4 44.4 5/8 15.9 .027 .69 100 10.6 4.8
HBCP8 2 50.8 5/8 15.9 .027 .69 100 11.5 5.2
HBCP9 2-1/4 57.1 5/8 15.9 .027 .69 100 12.6 5.7
HBCP10 2-1/2 63.5 5/8 15.9 .027 .69 50 6.8 3.1
HBCP11 2-3/4 69.8 5/8 15.9 .027 .69 50 7.3 3.3
HBCP12 3 76.2 5/8 15.9 .027 .69 50 7.7 3.5
HBCP14 3-1/2 88.9 5/8 15.9 .027 .69 50 8.7 3.9
HBCP16 4 101.6 5/8 15.9 .027 .69 25 4.9 2.2
HBCP18 4-1/2 114.3 5/8 15.9 .027 .69 25 5.5 2.5
HBCP20 5 127.0 5/8 15.9 .027 .69 25 5.9 2.7
HBCP24 6 152.4 5/8 15.9 .027 .69 25 6.8 3.1
HBCP28 7 177.8 5/8 15.9 .027 .69 25 7.4 3.4
HBCP32 8 203.2 5/8 15.9 .027 .69 25 8.2 3.7
STRAPBINDER.COM | 3
