Classic Standard Duty No-Hub Coupling
Description
A quality line of standard duty couplings that are assembled in Mexico using USA steel and gaskets. Manufactured with the same high quality as our other couplings, but at a lower price point. In full compliance with ASTM 564, CISPI 310 and ASTM C1277, and also carries IAPMO, Canadian Std Association and NSF certification.
Specifications
Shield Material: 301 SS
Band Material: 301 SS
Housing Material: 301 SS
Screw Material: 305 SS
Eyelet Material: 300 SS
Gasket Material: ASTM C564 Compliant
Installation Torque: 60 in-lbs
Ultimate Torque: 75 in-lbs
| Size | Item # | Installation Torque Inch-Pounds | No. Clamps Per Coupling |
|---|---|---|---|
| 1-1/2" | 621708G | 60 | 2 |
| 2" | 621808G | 60 | 2 |
| 3" | 621908G | 60 | 2 |
| 4" | 622008G | 60 | 2 |
| 5" | 622108G | 60 | 4 |
| 6" | 622208G | 60 | 4 |
| 8" | 622308G | 60 | 4 |
| 10" | 623008G | 60 | 4 |
| 2" x 1-1/2" | 62R218G | 60 | 2 |
| 3" x 2" | 62R328G | 60 | 2 |
| 4" x 3" | 62R438G | 60 | 2 |
